Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
477
Machining
position
• Single position
Mill rectangular pocket at the programmed position (X0, Y0, Z0).
• Position pattern
X0
Y0
Z0
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or de-
grees
mm
CP
X0 or L0
Y0 or C0
Z0
The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or de-
grees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de-
grees
mm
mm
C0
Y0
Z0
X0
The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
α0 Angle of rotation of slot
Face: α0 refers to the X axis or to the position of C0 with a polar reference point
Peripheral surface: α0 refers to the Y axis
Degrees
Slot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇ and ∇∇∇)
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
Maximum depth infeed - (only for ∇, ∇∇∇ and ∇∇∇ edge)
