Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
486 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C:
The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or de-
grees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y:
The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or de-
grees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C:
The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de-
grees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y:
The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
N
Number of slots
R
Radius of circumferential slot
mm
α0
Starting angle
Degrees
α1
Opening angle of the slot
Degrees
α2
Advance angle - (for pitch circle only)
Degrees
W
Slot width
mm
Z1
Slot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇, ∇∇∇)
mm
DZ
Maximum depth infeed - (only for ∇, ∇∇∇ )
mm
UXY
Plane finishing allowance – (only for ∇, ∇∇∇)
mm
