Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
487
Parameter
Description
Unit
Positioning
Positioning motion between the slots:
• Straight line:
Next position is approached linearly in rapid traverse.
• Circular:
Next position is approached along a circular path at the feedrate
defined in a machine data code.
FS Chamfer width for chamfering (inc) - (for chamfering only) mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering only)
mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
Milling direction
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
