Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
488 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇∇∇ edge (edge finishing)
• Chamfering
FZ (only for G code)
Depth infeed rate
*
Circular pattern
• Full circle
The circumferential slots are positioned around a full circle. The distance from
one circumferential slot to the next circumferential slot is always the same and
is calculated by the control.
• Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from
one circumferential slot to the next circumferential slot can be defined using
angle α2.
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C
: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y
: The positions refer to the reference point:
Positioning angle for machining area
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C
: The positions refer to the reference point:
Reference point Y or reference point angle polar
Reference point Z
Cylinder diameter ∅
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y
: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
