Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
497
Technology
• Vortex milling
The milling cutter performs circular motions along the length of the slot and
back again.
• Plunge cutting
Sequential drilling motion along the tool axis.
Milling direction: - (except plunge cutting)
• Climbing
• Conventional
• Climbing-conventional milling
Machining
position
• Single position
Mill a slot at the programmed position (X0, Y0, Z0).
• Position pattern
Mill slots at a programmed position pattern (e.g. full circle or grid).
X0
Y0
Z0
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
X0 or L0
Y0 or C0
Z0
The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
CP
X0 or L0
Y0 or C0
Z0
The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or de-
grees
mm
Y0 or C0
Z0
X0
The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de-
grees
mm
mm
C0
Y0
Z0
X0
The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
