Programming technology functions (cycles)
9.4 Milling
Turning
498 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
α0
Angle of rotation of slot
Degrees
Z1
(only for G code)
Slot depth (abs) or depth relative to Z0 (abs) – (only for ∇, ∇∇∇, ∇∇∇ base and
∇∇)
mm
Z1 or X1
(only for ShopTurn)
Slot depth (abs) or depth relative to Z0 or X0 (abs) – (only for ∇, ∇∇∇, ∇∇∇ base
and ∇∇)
(Z1 for machining surface, face C/Y or X1 for peripheral surface C/Y)
mm
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇)
mm
%
DZ Maximum depth infeed - (only for ∇, ∇∇, ∇∇∇ and ∇∇∇ edge)
- (only for vortex milling)
mm
UXY
Plane finishing allowance (slot edge) - (only for ∇, ∇∇ and ∇∇∇ base)
mm
UZ
Depth finishing allowance (slot base) - (only for ∇, ∇∇ and ∇∇∇ edge)
mm
FS
Chamfer width for chamfering (inc) - (for chamfering only)
mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering only)
mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
