Programming technology functions (cycles)
9.4 Milling
Turning
510 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
4 places before decimal point,
leading blanks, no places after the
decimal point
Places before and after the dec
i-
Places before decimal point u
n-
1 place after the decimal point
(rounded)
Places before decimal point u
n-
2 places after the decimal point
(rounded)
Places before decimal point u
n-
4 places after the decimal point
(rounded)
If there is insufficient space in front of the decimal point to display the
number
entered, it is automatically extended. If the specified number of
digits is larger than the number to be engraved, the output format is
automatically filled with the appropriate number of leading and trailing
zeroes.
You can optionally use blanks to format
before the decimal place.
Instead of _VAR_NUM you can use any other numeric variable (e.g.
R0).
Press the "Variable" and "Variable text" softkeys if you want to take the
text to be engraved (up to 200 characters) from a variable.
The format text <Text, _VAR_TEXT> is inserted and you return to the
engraving field with the softkey bar.
You can use any other text variable instead of _VAR_TEXT.
Note
Entering the engraving text
Only single
-line entries without line break are permissible!
