Programming technology functions (cycles)
9.5 Contour milling
Turning
518 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
PL
(only for G code)
Machining plane
• G17 (XY)
• G19 (YZ)
Ï•
Cylinder diameter
(only peripheral surface C)
mm
G17
or
face C/Y/B
G19
or
peripheral
X
Y
Starting point X or Y (abs)
Starting point Y or Z (abs)
mm
X
Y
Position pole (abs)
mm
Starting point
L1
Distance to pole, end point (abs)
Polar angle to the pole, end point (abs)
mm
Additional commands You can program feedrates and M commands, for example, using additional G
code commands. However, carefully ensure that the additional commands do
not collide with the generated G code of the contour and are compatible with
the machining type required. Therefore, do not use any G code commands of
group 1 (G0, G1, G2, G3), no coordinates in the plane and no G code com-
mands that have to be programmed in a separate block.
The contour is finished in continuous-path mode (G64). As a result, contour
transitions such as corners, chamfers or radii may not be machined precisely.
If you wish to avoid this, then it is possible to use additional commands when
programming.
Example: For a contour, first program the straight X parallel and then enter
"G9" (non-modal exact stop) for the additional command parameter. Then pro-
gram the Y-parallel straight line. The corner will be machined exactly, as the
feedrate at the end of the X-parallel straight line is briefly zero.
The additional commands are only effective for path milling!
