Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.5 Contour milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
523
Contour element "Circle"
Parameters
Description
Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
Direction of rotation
• Clockwise direction of rotation
• Counterclockwise direction of rotation
R
Radius
mm
e.g. X
End point X (abs or inc)
mm
e.g. Y
End point Y (abs or inc)
mm
e.g. I
Circle center point I (abs or inc)
mm
e.g. J
Circle center point J (abs or inc)
mm
α1
Starting angle to X axis
Degrees
α2
Angle to the preceding element
Degrees
β1
End angle to Z axis
Degrees
β2
Opening angle
Degrees
Transition to next ele-
ment
Type of transition
• Radius
• Chamfer
Radius R Transition to following element - radius mm
Chamfer
FS
Transition to following element - chamfer
mm
Additional commands
Additional G code commands
Contour element "Pole"
Parameters
Description
Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
X
Y
Position pole (abs)
Position pole (abs)
mm (in)
Degrees
