Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.5 Contour milling
Turning
522 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Contour element "straight line, e.g. Y"
Parameters
Description
Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
Y
End point Y (abs or inc)
mm
α1
Starting angle to X axis
Degrees
Transition to next ele-
ment
Type of transition
• Radius
• Chamfer
Radius
R
Transition to following element - radius
mm
Chamfer
FS
Transition to following element - chamfer
mm
Additional commands
Additional G code commands
Contour element "Straight line e.g. XY"
Parameters
Description
Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
X
End point X (abs or inc)
mm
Y
End point Y (abs or inc)
mm
L
Length
mm
α1
Starting angle e.g. to the X axis
Degrees
α2
Angle to the preceding element
Degrees
Transition to next ele-
ment
Type of transition
• Radius
• Chamfer
Radius
R
Transition to following element - radius
mm
Chamfer
FS
Transition to following element - chamfer
mm
Additional commands
Additional G code commands
