Programming technology functions (cycles)
9.5 Contour milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
539
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Please refer to the machine manufacturer's specifications.
For simple machining operations, you have the option to reduce the wide variety of
parameters to the most important parameters using the "Input" selection field. In this "Input
simple" mode, the hidden parameters are allocated a fixed value that cannot be adjusted.
Various defined values can be pre
-assigned using setting data.
Please refer to the machine manufacturer's specifications.
If the workpiece programming requires it, you can display and change all of the parameters
using "Input complete".
For solid machining, you can select the machining type (roughing or finishing). If you want to
rough and then finish, you have to call the machining cycle twice (block 1 = roughing, block 2
= finishing). The programmed parameters are retained when the cycle is called for the
second time.
During insertion with oscillation, the message "Ramp path too short" will appear if the tool is
less than the milling cutter diameter away from the insertion point along the ramp, or the
machining depth is not reached.
● Reduce the insertion angle if the tool remains too close to the insertion point.
● Increase the insertion angle if the tool does not reach the machining depth.
● If necessary, use a tool with a smaller radius of select a different insertion mode.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
.
Press the "Milling", "Contour milling" and "Pocket" softkeys.
The "Mill pocket" input window opens.
