Programming technology functions (cycles)

9.5 Contour milling

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

551

Parameter

Description

Depth finishing allowance (only for ∇ and ∇∇∇ base)

FS Chamfer width for chamfering - (for chamfering only) mm

ZFS

Insertion depth of tool tip (abs or inc) - (for chamfering only)

* Unit of feedrate as programmed before the cycle call

Hidden parameters

The following parameters are hidden. They are pre-assigned fixed values or values that can

be adjusted using setting data.

Parameter

Description

Value

Can be set in SD

PL (only for G

code)

Machining plane Defined in MD

52005

SC (only for G

code)

Safety clearance 1 mm x

Lift mode Lift mode before new infeed - (only for ∇, ∇∇∇ base or ∇∇∇

edge)

to RP

Machine manufacturer

Please refer to the machine manufacturer's specifications.
