Siemens SINUMERIK 828D - Page 554

Programming technology functions (cycles)
9.5 Contour milling
Turning
554 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
parameters
Description
Unit
Z1
Pocket depth (abs) or depth referred to Z0 mm
CP Positioning angle for machining area
- (only for ShopTurn, machining surface, face Y)
Degrees
C0 Positioning angle for machining surface
- (only for ShopTurn, machining surface, peripheral surface Y)
Degrees
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
mm
%
DZ
Maximum depth infeed
Lift mode
Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction
height can be programmed:
• To retraction plane
• Z0 + safety clearance
When making the transition to the next insertion point, the tool returns to this
height. If there are no elements larger than Z0 in the pocket area, Z0 + safety
clearance" can be selected as the lift mode.
mm
mm
FS
Chamfer width for chamfering - (only for chamfering machining)
mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering machining only)
mm
