Siemens SINUMERIK 828D

Programming technology functions (cycles)
9.6 Further cycles and functions
Turning
562 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
TC
Name of swivel data set
Retract
- (only for G
code)
No No retraction before swiveling
Incremental retraction in tool direction
The retraction path is entered into parameter ZR
When retracting in the tool direction, in the swiveled
machine state, several axes can move (traverse)
Maximum retraction in tool direction
Retraction in the direction of machine axis Z.
Retract towards the machine axis Z and then in the
direction X, Y
ZR
Retraction path - (only for incremental retraction in the tool direction)
mm
Swivel plane
- (only for G
code)
• New: New swivel plane
• Additive: Additive swivel plane
RP - (only for
ShopTurn)
Retraction plane for face B
C0 - (only for
ShopTurn)
Position angle for machining surface Degrees
X0
Reference point for rotation X
Y0
Reference point for rotation Y
Z0
Reference point for rotation Z
Swivel mode
• Axis-by-axis: Swivel coordinate system axis-by-axis
• Solid angle: Swivel via solid angle
• Proj. angle: Swiveling via projection angle
• Direct: Directly position rotary axes
Axis sequence Sequence of the axes which are rotated around - (only for axis-by-axis swivel mode)
XYZ or XZY or YXZ or YZX or ZXY or ZYX
X
Rotation around X
- (only for axis sequence)
Degrees
Y
Rotation around Y
Degrees
Z
Rotation around Z
Degrees
Projection posi-
tion
Position of the projection in space - (only for swivel mode, projection angle)
Xα, Yα, Zβ or Yα, Zα, Zβ or Zα, Xα, Zβ
Xα
Projection angle
- (only for projection position)
Degrees
Yα
Projection angle
Degrees
Zβ Angle of rotation in the plane Degrees
Z
Angle of rotation in the plane
Degrees
X1
Zero point of rotated surface X
Y1
Zero point of rotated surface Y
Z1
Zero point of rotated surface Z
Direction - (only
for G code)
Preferred direction, rotary axis 1 - (not for swivel mode direct)
• +
• -
