Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
607
Parameter
Description
Unit
Flush chuck Flush counter-spindle chuck
• Yes
• No
DIR Direction of rotation
•
Spindle rotates clockwise
•
Spindle rotates counter-clockwise
•
Spindle does not rotate
S
Spindle speed – (only when the spindle rotates)
rev/min
α1 Angular offset Degrees
Z1
Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
FR
Reduced feedrate
mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counter-spindle stops at a defined distance away from transfer position
Z1 and then traverses with a defined feedrate up to the fixed stop.
• No
The counter-spindle traverses to the transfer position Z1.
Parameter
Description
Unit
Function, withdrawing
Withdraw blank
• From main spindle
The blank is withdrawn from the main spindle
• From counter-spindle
The blank is withdrawn from the counter-spindle
Also take zero point Also take zero point
• Yes
• No
Work offset
- only when for "with-
draw NP" "yes"
Work offset in which the coordinate system offset by Z1 must be saved.
• Basic reference
• G54
• G55
• G56
• G57
• ...
Z1
Amount by which the workpiece is withdrawn from the main spindle (inc)
F
Feedrate
mm/min
