Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
606 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
Work offset Work offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
Basic reference
• G54
• G55
• G56
• G57
• ...
Write to the
work offset
• Yes
The Z value of the work offset can be directly written to the input screen
form.
• No
The actual Z value of the work offset is used.
ZV - only for work offset
write "yes"
• Offset Z = 0 (abs)
• Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
mm
Z4P
Machining position for special axis (abs.); machine coordinate system
mm
Parameter
Description
Unit
Function, gripping
Teaching in the park position and angular offset is possible
Gripping a blank
• With main spindle
The blank is gripped with the main spindle
• With counter-spindle
The blank is gripped with the counter-spindle
Work offset -
only for "with main
spindle"
Buffer work offset:
• Basic reference
• G54
• G55
• G56
• G57
• ...
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching in
the park position and angular offset is only possible in the machine coordinate
system.
• WCS
The park position is specified in the workpiece coordinate system.
XP
Park position of tool in X direction (abs)
mm
ZP
Park position of tool in Z direction (abs)
mm
