Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
605
Parameter
Description
Unit
Fixed
stop
Travel to fixed stop
• Yes
The counter-spindle stops at a defined distance away from transfer position
Z1 and then traverses with a defined feedrate up to the fixed stop.
• No
The counter-spindle traverses to the transfer position Z1.
Withdrawing
Withdraw blank Withdraw complete blank:
• Yes
• No
F
Feed - withdraw for blank "yes"
mm/min
Cutting-off
cycle
Cutting-off cycle in the following block
• Yes
• No
Rear face
- for main spindle in counter-spindle
Work offset Work offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
• Basic reference
• G54
• G55
• G56
• G57
• ...
Write to the
work offset
• Yes
The Z value of the work offset can be directly written to the input screen
form.
• No
The actual Z value of the work offset is used.
ZV - only for work offset
write "yes"
• Offset Z = 0 (abs)
• Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
mm
Z4W
Machining position for special axis (abs.); machine coordinate system
mm
Front face
- for counter-spindle in main spindle
