Multi-channel machining
10.2 Multi-channel support
Turning
632 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
ZA
Initial dimension
mm
ZI Final dimension (abs) or final dimension in relation to ZA (inc) mm
ZB Machining dimension (abs) or machining dimension in relation to
ZA (inc)
Retraction The retraction area indicates the area outside of which collision-free traversing
of the axes must be possible.
• simple
XRA Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI
- only for "pipe" blank
Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
• extended
-
not for a "pipe" blank
mm
XRA Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
• all
mm
XRA Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
XRI Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
ZRI Retraction plant Z rear mm
Tailstock
• Yes
• No
XRR
Retraction plane tailstock – only "Yes" for tailstock
mm
Tool change point
Tool change point, which must be approached by the revolver with its zero point.
• WCS (Workpiece Coordinate System)
• MCS (Machine Coordinate System)
Notes
• The tool change point must be far enough outside the retraction area that it
is not possible for any tool to protrude into the retraction area while the re-
volver is moving.
• Ensure that the tool change point is relative to the zero point of the revolver
and not the tool tip.
XT
Tool change point X ∅
mm
