Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
633
Parameter
Description
Unit
ZT
Tool change point Z
mm
S Spindle speed rev/min
Spindle chuck data
• Yes
You enter spindle chuck data in the program.
• No
Spindle chuck data are transferred from the setting data.
Note
:
Please observe the machine manufacturer’s instructions.
Spindle chuck data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note
:
Please observe the machine manufacturer’s instructions.
Data for
If several spindles have been set up, the program can operate at both spindles.
Select the 2nd spindle
• Main spindle
• Counterspindle
• Empty
The program only operates at one spindle
Retraction The retraction area indicates the area outside of which collision-free traversing
of the axes must be possible.
•
simple
•
extended
– not for a "pipe" blank
•
all
XRA Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI - for "basic" retraction, only for a "pipe" blank
retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
ZRI
Retraction plane Z rear – only for retraction "all"
mm
Tailstock
• Yes
• No
XRR
Retraction plane tailstock – only "Yes" for tailstock
mm
