Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
661
Parameters
Description
Unit
Complete transfer
function
Withdrawing
Withdraw blank Withdraw complete blank:
• Yes
• No
F
Feed (only when "yes" for "withdraw blank")
mm/min
Cutting-off
cycle
Cutting-off cycle in the following block
• Yes
• No
Complete transfer
function
Rear side (for main spindle in counter-spindle)
Work offset Work offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
• Basic reference
• G54
• G55
• G56
• G57
• ...
Write to the
work offset
• Yes
The Z value of the work offset can be directly written to the input screen
form.
• No
The actual Z value of the work offset is used.
ZV - only for
work offset
write "yes"
• Offset Z = 0 (abs)
• Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
mm
Z4W
Supplementary axis of the counter-spindle machining position (abs); MCS
mm
Complete transfer
function
Front side (for counter-spindle in main spindle)
Work offset Work offset in which the coordinate system, which was shifted according to ZP
and by ZV as well as mirrored in Z, must be saved:
Basic reference
G54
G55
G56
G57
...
