Multi-channel machining
10.2 Multi-channel support
Turning
662 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
Work offset
write to
• Yes
The Z value of the work offset can be directly written to the input screen
form.
• No
The actual Z value of the work offset is used.
ZV - only for
work offset
write "yes"
• Z value of the work offset (abs)
• Workpiece zero offset in the Z direction (inc); the sign is also evaluated.
mm
Z4P
Park position of the counter-spindle supplementary axis (abs); MCS
mm
Parameters
Description
Unit
Function, gripping
Teaching in the park position and angular offset is possible
Gripping a blank
• With counter-spindle
The blank is gripped with the counter-spindle
• With main spindle
The blank is gripped with the main spindle
Also take zero point
• Yes
• No
Work offset
- for take zero point
"yes"
Work offset in which the coordinate system offset by Z1 must be saved.
Basic reference
G54
G55
G56
G57
...
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching in
the park position and angular offset is only possible in the machine coordinate
system.
• WCS
The park position is specified in the workpiece coordinate system.
XP
Park position of tool in X direction (abs)
mm
ZP
Park position of tool in Z direction (abs)
mm
Flush chuck Flush counter-spindle chuck
• Yes
• No
DIR Direction of rotation
•
Spindle rotates clockwise
•
Spindle rotates counter-clockwise
•
Spindle does not rotate
