Siemens SINUMERIK 828D User Manual

Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
663
Parameters
Description
Unit
S
Spindle speed – (only when the spindles rotate)
rev/min
α1 Angular offset Degrees
Z1
Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
FR
Reduced feedrate
mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counter-spindle stops at a defined distance away from transfer position
Z1 and then traverses with a defined feedrate up to the fixed stop.
• No
The counter-spindle traverses to the transfer position Z1.
Parameters
Description
Unit
Function, withdrawing
Withdraw blank
• From main spindle
• From counter-spindle
Also take zero point Also take zero point
• Yes
• No
Work offset
- for take zero point
"yes"
Work offset in which the coordinate system offset by Z1 must be saved.
• Basic reference
• G54
• G55
• G56
• G57
• ...
Z1
Amount by which the workpiece is withdrawn from the main spindle (inc)
F
Feedrate
mm/min
Parameters
Description
Unit
Machining side function
Spindle selection
• Main spindle
Machining along the main spindle
• Counter-spindle
Machining along the counter-spindle
