Key Adjustments (Key Control Block) 147
Applicable
block
Key to
which
DME
effects
are
applied
DME wipe
pattern for
background
Number of keys
to which DME
effects can be
applied
simultaneously
Other than
M/E-4
Keys 1
to 4
No DME
wipe used
2
One-channel
mode
1
Two- or
three-
channel
mode
0
Keys 5
to 8
-
2
a)
M/E-4
Keys 1
to 4
No DME
wipe used
2
b)
One-channel
mode
1
c)
Two- or
three-
channel
mode
0
Keys 5
to 8
-
0
Chapter
4
Keys
- MVS-8000X 2 Using the DME channel selection buttons, select the
DME channel (DME1 to DME8) for applying the
effect.
The lit colors of the [DME1] to [DME8] buttons
indicate the DME assignment.
Lit green: Shows the DME assigned to the currently
selected key.
Lit amber: Shows the DME assigned to a key other
than the currently selected key.
Off: DME is not assigned.
To select a DME being used by another keyer
Press [Override], turning it on, then select the DME
channel.
The later selection is valid, and the button lights green.
Using two or three DME channels on one keyer
When using the DME dedicated interface, proceed as
follows.
- MVS-7000X
Key to
which
DME
effects are
applied
DME wipe pattern
for background
Number of keys to
which DME effects
can be applied
simultaneously
Keys 1 to 4
No DME wipe used
2
One-channel mode
1
Two- or three-
channel mode
0
Keys 5 to 8
-
2
a)
a) 0 when the system signal format is 1080P.
b) 1 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
c) 0 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
• When combining DMEs connected via the dedicated
interface and the SDI interface, you can increase the
number of keys to which DME effects are applied
simultaneously (requires a setting in setup).
For details, see “Setting DME and Switcher Interfaces”
in Chapter 20 (Volume 2).
Assigning a DME to a key
1 In the key control block, press the delegation buttons
[M/E 1] and [KEY1].
Notes
On the MVS-8000X, when the signal format is 1080P, the
combination of two consecutively numbered DME
channels that can be selected is DME1 and DME2, DME3
and DME4, DME5 and DME6, or DME7 and DME8. It is
not possible to combine three or more DME channels.
On the MVS-7000X, when the signal format is 1080P, the
above restriction also applies if using the MVE-8000A.
There is no such restriction for the MKS-7470X.
1 Select the DME for the first channel (see the previous
item, “Assigning a DME to a key”), then select the
successive channel for the second channel. For the
third channel select the channel after that.
2 To select the second channel video signal, hold down
the [UTIL] button in the cross-point control block, and
select the signal in the Key1 row (DME external video
bus).
3 To select the third channel video signal, when the
selected DME is Ch3 or Ch4, select the signal on the
DME utility 1 bus. When the selected DME is Ch7 or
Ch8, select the signal on the DME utility 2 bus.
For details of the method of signal selection, see “Bus
Selection” (page 89).
Using four DME channels on one keyer
When using the DME dedicated interface, proceed as
follows.
