Configuration Guide 474

Configuring Voice VLAN Configuration Example

Figure 3-5 Configuring Voice VLAN Mode on Port 1/0/2

4) Choose the menu VLAN > 802.1Q VLAN > VLAN Config and edit VLAN 10 to load the

following page. Add port 1/0/2 to the voice VLAN.
