3-30
System diagram
(*1). Resistor cap
(*2). Joint connector
A. Main station
B. Joystick station
a. Power port
b. Bus port
c. Device port
P. Port
S. Starboard
TIP:
The part numbers are subject to change without notice. Make sure to confirm the latest part numbers.
19 BCU 6X9-8591T-23
20 Key fob and receiver assembly
6X9-86254-04
Radio frequency 433 MHz,
Key fob: 2 pcs.
6X9-86254-13
Radio frequency 315 MHz,
Key fob: 2 pcs.
21 Multi-hub 6Y8-81920-01 w/ resistor cap, Gray
22 Main bus wire
6Y8-82553-01 0.3 m (1 ft)
6Y8-82553-50 3.0 m (10 ft)
6Y8-82553-11 4.6 m (15 ft)
6Y8-82553-21 6.1 m (20 ft)
6Y8-82553-31 7.6 m (25 ft)
6Y8-82553-41 9.1 m (30 ft)
23 System power supply wire 6Y8-83553-02 w/ 10 A fuse, 2.4 m (8 ft)
24 Conversion harness 6Y9-83553-00 DEC to hub, 0.3 m (1 ft)
25 Conversion harness 6YM-83553-00 0.9 m (3 ft)
26 CL5 display 6YM-83710-14 No Wi-Fi
27 Tank wire 6YD-8356N-00
28 Fuel tank —
29 Heading sensor 6X9-8A410-01
30 Single (inline) hub 6Y8-81920-11 w/ resistor, 4–6P, White
31 GPS unit 6X9-88107-02
32 Propeller light 6KA-83720-00
33 Extension wire harness
6X9-83553-70 7 m (23 ft)
6X9-83553-80 10 m (32 ft)
34 Aux joystick harness 6X9-82580-G0
35 All start/stop switch 6X9-82570-B1
36 Engine shut-off switch 6X9-82570-D1 Joystick station
Ref.
No.
Part name Part No. Remarks
