Yamaha F400A 2022 - Camshaft

7-46
Camshaft
Camshaft
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
60 N
·
m (6.0 kgf
·
m, 44 lb
·ft
)
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
17 N
·
m (1.7 kgf
·
m, 13 lb
·ft
)
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
60 N
·
m (6.0 kgf
·
m, 44 lb
·ft
)
1
2
1
2
1377B1377B
1280B1280B
1280B1280B
1280B1280B
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
1386B1386B
19
29
29
29
29
17
18
37
38
39
37
37
28
37
30
New
30
New
13
16
25
24
28
27
26
20
36
22
21
31
28
32
34
25
25
24
26
24
24
20
17
36
28
35
27
14
New
12
New
New
4
1
5
1
1
1
3
2
9
11
33
23
31
21
9
6
7
15
14
8
10
25
Part name
Q
’ty
Remarks
1Bolt M6
× 16 mm 13
2 Bracket 1
3Guide 1
4 Bracket 1
5Guide 1
6Bolt M6
× 25 mm 1
7 Hose nipple 1
8O-ring 1
9Bolt M6
× 30 mm 44
10 Cover 1
11 Cover 1
12 Gasket 1
13 Gasket 1
14 Screw M4
× 7 mm 16
15 Plate 1
16 Plate 1
17 Bolt M10
× 35 mm 2
18
Driven sprocket
(PORT)
1
19
Driven sprocket
(STBD)
1
20 Bolt M12
× 35 mm 2
Left-hand
threads
21 Bolt M6
× 25 mm 4
22 Tensioner (PORT) 1
23 Tensioner (STBD) 1
24 Bolt M7
× 48 mm 8
25 Bolt M7
× 37 mm 36
26 Camshaft cap 2
27 Camshaft cap 2
28 Camshaft cap 18
29 Dowel 8
30 Oil seal 2
31 Chain 2
32 Camshaft (PORT EX) 1
33 Camshaft (STBD EX) 1
34 Camshaft (PORT IN) 1
35 Camshaft (STBD IN) 1
Part name
Q
’ty
Remarks
