Yamaha F400A 2022 - Assembling the Upper Case; Installing the Muffler and Upper Case

9-30
Upper case, muffler, and oil pan
b. Install the bolts (M10 × 70 mm) “1” and
bolts (M10 × 120 mm) “2”, and then
tighten the bolts to the specified
torques in 2 stages and in the order [1],
[2], and so on.
c. Tighten the bolt “1” to the specified
torque.
Assembling the upper case
1. Install:
•Grommet
• Drive shaft bushing “1”
A
B
Installing the muffler and upper case
1. Install:
•Dowels
•Gasket
• Muffler
• Muffler bolts (M10 × 70 mm) “1”
• Muffler bolts (M6 × 30 mm) “2”
•Rubber seals
• Water pipe
T
R
.
.
Oil pan bolt “1”, “2”
1st: 42 N·m (4.2 kgf·m, 31 lb·ft)
2nd: 42 N·m (4.2 kgf·m, 31 lb·ft)
T
R
.
.
Oil pan bolt “1”, “2”
1st: 42 N·m (4.2 kgf·m, 31 lb·ft)
2nd: 42 N·m (4.2 kgf·m, 31 lb·ft)
T
R
.
.
Oil pan bolt “1”
42 N·m (4.2 kgf·m, 31 lb·ft)
2
1
2
2
1 2
[1][1][1]
[2][2][2]
[3][3][3]
[4][4][4]
[5][5][5]
[1][1]
[2][2]
[3][3]
[4][4]
[5][5]
572572
LTLT
2
1
2
1 2
[8][8][8]
[1][1][1]
[2][2][2]
[3][3][3]
[4][4][4]
[5][5][5]
[6][6][6]
[7][7][7]
[13][13][13]
[14][14][14]
[10][10][10]
[15][15][15]
[12][12][12]
[16][16][16]
[17][17][17]
[11][11][11]
[8][8]
[9][9][9][9][9]
[1][1]
[2][2]
[3][3]
[4][4]
[5][5]
[6][6]
[7][7]
[13][13]
[14][14]
[10][10]
[15][15]
[12][12]
[16][16]
[17][17]
[11][11]
572572
LTLT
1
A. Worldwide
B. USA and Canada
Driver rod LL “2”
90890-06605
Ball bearing attachment “3”
90890-06636
Driver handle (small) “4”
YB-06229
Driveshaft seal installer “5”
YB-06348
New
WR-No.2WR-No.2
3
2
1
2
3
5
4
1
WR-No.2WR-No.2
4
5
New
