Yamaha F400A 2022 - Exhaust Joint (Outside)

Exhaust joint (outside)
7-7
Exhaust joint (outside)
20
New
19
22
New
14
14
17
1516
New
New
16
23
20
New
19
New
10
9
21
1
2
New
1
26
New
28
27
25
26
New
28
27
25
10
9
8
7
18
14
13
New
13
New
New
1
New
1
3
New
1
6
5
4
14
EE
EE
24
11
12
13031303
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
19 N
·
m (1.9 kgf
·
m, 14 lb
·ft
)
21 N
·
m (2.1 kgf
·
m, 15 lb
·ft
)
11 N
·
m (1.1 kgf
·
m, 8.1 lb
·ft
)
23 N
·
m (2.3 kgf
·
m, 17 lb
·ft
)
1
2
Part name
Q
’ty
Remarks
1 Plastic tie 7
2Hose 1
3Holder 2
4Hose 1
5Joint 1
6Hose 1
7 Coupler 1 Disconnect.
8Sensor 1
Water pres-
sure
9Bolt M8
× 50 mm 12
10 Bolt M8
× 110 mm 10
11 Bolt M8
× 70 mm 4
12
Exhaust joint assem-
bly
1
13 Gasket 2
14 Dowel 4
15 Gasket 1
16 Dowel 2
17 Exhaust joint 1 PORT
18 Exhaust joint 1 STBD
19 O-ring 2
20 O-ring 2
21 Exhaust joint 1 Lower
22 Holder 2
23 Bolt M6
× 16 mm 1
24 Bracket 1
25 Plug M16
× 11 mm 2
26 O-ring 2
27 Screw M5
× 25 mm 2
28 Anode 2
Part name
Q
’ty
Remarks
