CL5 display calibration
3-67
CL5 display calibration
• If the steering actuator is removed, the steer-
ing sensor must be calibrated after the unit is
installed.
• Check that the battery is fully charged before
performing the calibration. Otherwise, the
calibration cannot be performed properly.
• Do not turn the steering wheel while the cal-
ibration is being performed.
Steering calibration is not required with the
factory default setting.
Configuring the number of outboard
motors
1. Turn the power switch to “ON”.
2. Open the menu screen by swipe.
3. Tap “Reset”.
4. Tap “Number of Engines”.
5. Select the number of outboard motors
mounted on the boat.
6. Tap “Reset” to confirm that the number of
outboard motors has been changed.
Accessing the calibration menu
1. Open the menu screen by swipe.
2. Tap and hold the “Menu” bar for 10 sec-
onds. The “Technician Settings” menu will
be added to the menu.
Tap while the screen is scrolled all the way to
the top.
