Yamaha F400A 2022 - PTT Cylinder

9-62
PTT cylinder
PTT cylinder
15 N
·
m (1.5 kgf
·
m, 11 lb
·ft
)
65 N
·
m (6.5 kgf
·
m, 48 lb
·ft
)
150 N
·
m (15 kgf
·
m, 111 lb
·ft
)
160 N
·
m (16 kgf
·
m, 118 lb
·ft
)
65 N
·
m (6.5 kgf
·
m, 48 lb
·ft
)
65 N
·
m (6.5 kgf
·
m, 48 lb
·ft
)
15 N
·
m (1.5 kgf
·
m, 11 lb
·ft
)
New
New
New
New
New
New
New
New
New
New
New
New
New
16
18
19
14
15
17
23
22
22
34
10
30
29
8
24
12
13
21
20
2
3
4
5
2
3
4
1
7
6
38
37
26
11
36
35
7
9
9
25
31
32
33
28
27
Part name
Q
’ty
Remarks
1Pipe 1
2Circlip 2
3Cap 2
4O-ring 2
5Spring 1
6Shaft 1
7O-ring 4
8 Tilt cylinder assembly 1
9 Spacer 2
10 Tilt cylinder end screw 1
11 Tilt ram assembly 1
12 Free piston 1
13 O-ring 1
14 Circlip 1
15
Trim cylinder end
screw
2
16 O-ring 2
17 Trim ram assembly 2
18 Circlip 2
19 Dust seal 2
20 Nut 1
21 Washer 1
22 Ball 4
3.92 mm
(0.15 in) (ref-
erence data)
23 Tilt piston 1
24 Backup ring 1
25 O-ring 1
26 O-ring 1
27 Adapter 1
28 Spring 1
29 Tilt cylinder end 1
30 Dust seal 1
31 O-ring 1
32 Backup ring 1
33 O-ring 1
34 Tilt rod 1
35 Circlip 2
Part name
Q
’ty
Remarks
