Yamaha F400A 2022 - Bottom Cowling (PORT and STBD)

Bottom cowling (PORT and STBD)
9-3
Bottom cowling (PORT and STBD)
11
3
46
44
43
5
4
16
29
17
18
27
20
21
19
26
24
23
22
45
14
1413
14
31
32
28
12
13
13
6
15
34
35
36
46
1
2
43
8
9
7
13
12
31
44
45
33
17
18
27
14
14
15
28
22
23
25
26
19
27
20
21
30
16
37
39
41
40
38
10
42
1342H1342H
572572
LTLT
19 N
·
m (1.9 kgf
·
m, 14 lb
·ft
)
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
0.9 N
·
m (0.09 kgf
·
m, 0.66 lb
·ft
)
3.0 N
·
m (0.30 kgf
·
m, 2.2 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M6
× 14 mm 1
2Plate 1
3 Rubber seal 1
4Bolt M6
× 25 mm 7
5Bolt M6
× 14 mm 1
6
Bottom cowling
(STBD)
1
7Bolt M6
× 25 mm 5
8Bolt M6
× 14 mm 1
9
Bottom cowling
(PORT)
1
10 Rubber seal 1
11 Rubber seal 1
12 Collar 12
13 Grommet 14
14 Grommet 4
15 Bolt M6
× 12 mm 4
16 Bracket 2
17 Bolt M8
× 12 mm 2
18 Clamp lever 2
19 Shaft 2
20 Washer 2
21 Wave washer 2
22 Retaining clip 2
23 Pin 2
24 Lock lever (STBD) 1
25 Lock lever (PORT) 1
26 Washer 2
27 Bushing 4
28 Bolt M6
× 12 mm 4
29 Clamp plate (STBD) 1
30 Clamp plate (PORT) 1
31 Screw M5
× 16 mm 4
32 Damper (STBD) 1
33 Damper (PORT) 1
34 Screw M4
× 12 mm 2
35 Cover 1
36 Grommet 1
