Yamaha F400A 2022 - Cooling Water Hose and Gear Oil Changing Hose

Cooling water hose and gear oil changing hose
9-9
Cooling water hose and gear oil changing hose
572572
LTLT
572572
LTLT
572572
LTLT
New
New
New
New
New
New
New
New
New
572572
LTLT
572572
LTLT
572572
LTLT
20 N
·
m (2.0 kgf
·
m, 15 lb
·ft
)
4
5
3
4
6
7
25
ab
cd
c>d
24
24
26
22 23
13,14 16,17
7
32
32
31
35
31
10
11
14
15
18
2
17
7
6
4
12
12
12
12
7
5
13
33
34
16
8
29
4
1
27
21
19
20
23
22
28
30
9
a>b
Part name
Q
’ty
Remarks
1 Plastic tie 2
2Hose 1
3Hose 1
4Bolt M6
× 20 mm 4
5Joint 2
6Joint 2
7 Rubber seal 4
8 Plastic tie 2
9Band 2
10 Bolt M6
× 12 mm 1
11 Cover 1
12 Plastic tie 8
13 Hose (gear oil) 1
14 Hose (gear oil) 1
15 Joint (gear oil) 1
16 Hose (air) 1
17 Hose (air) 1
18 Joint (air) 1
19 Cover (gear oil) 1
“OIL”
20 Cover (air) 1 “AIR”
21 Quick connector 2
22 Hose fitting (gear oil) 1
23 Hose fitting (air) 1
24 Bolt M8
× 25 mm 2
25 Joint (gear oil) 1
26 Joint (air) 1
27 Bolt M6
× 12 mm 2
28 Hose holder 1
29 Bolt M6
× 16 mm 2
30 Holder 2
31 Bolt M6
× 12 mm 2
32 Holder 2
33 Cap 1
34 Grommet 1
35 Rubber seal 1
Part name
Q
’ty
Remarks
