Yamaha F400A 2022 - Etv

ETV
6-28
ETV
7
8
14
13
12
9
10
11
6
5
3
4
1
2
14
16
15
New
New
New
New
1
7 N
·
m (0.7 kgf
·
m, 5.2 lb
·ft
)
3.5 N
·
m (0.35 kgf
·
m, 2.6 lb
·ft
)
24 N
·
m (2.4 kgf
·
m, 18 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M6
× 25 mm 2
2 Intake silencer 1
3 Plastic tie 1
4Joint 1
5Bolt M8
× 60 mm 4
6 Bracket 1
7ETV 1
8Gasket 1
9Screw M5
× 16 mm 2
10 Sensor 1
Intake air
pressure/
temperature
11 O-ring 1
12 Bolt M8
× 35 mm 6
13 Surge tank 1
14 Dowel 2
15 Plastic tie 1
16 Hose 1
