Yamaha F400A 2022 - Flywheel Magneto

7-24
Flywheel magneto
Flywheel magneto
EE
2
2
2
3
4
5
7
11
14
8
13
13
10
15
16
10
9
1
12
6
New
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
8 N
·
m (0.8 kgf
·
m, 5.9 lb
·ft
)
1
2
40 N
·
m (4.0 kgf
·
m, 30 lb
·ft
)
1
2
90°
242242
LTLT
Part name
Q
’ty
Remarks
1Holder 1
2Bolt M6
× 16 mm 3
3Air shroud 1
4Bolt M6
× 16 mm 4
5Fan 1
6 Bolt M10
× 50 mm 6
7 Flywheel magneto 1
8Dowel 1
9Holder 1
10 Holder 2
11 Bolt M6
× 35 mm 6
12 Stator assembly 1
13 Bolt M6
× 30 mm 3
14 Base assembly 1
15 Bolt M6
× 16 mm 1
16 Bracket 1
