Yamaha F400A 2022 - Power Unit Assembly

Power unit assembly
7-13
Power unit assembly
1
2
3
4
14
15
16
17
13
B
D
New
24
50
50
New
49
New
New
New
51
40
39
42
26
27
37
28
C
New
24
26
29
37
25
31
7
7
10
41
43
44
45
46
46
47
36
6
6
5
5
11
12
26
37
5
7
7
32
34
33
8
30
48
22
18
18
18
25
23
19
21
20
35
9
38
A
572572
LTLT
WR-No.2WR-No.2
WR-No.2WR-No.2
572572
LTLT
572572
LTLT
7.6 N
·
m (0.76 kgf
·
m, 5.6 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1
2
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1
2
Part name
Q
’ty
Remarks
1Hose 1
2Hose 1
3Bolt M6
× 16 mm 1
4Guide 1
5Nut M6 3
6Cap 3
7Holder 7
8Holder 1
9Holder 1
10 Lead 1
11 Holder 2
12 Lead 1
13 Plastic tie 1
14 Retainer 1
15 Bolt M6
× 20 mm 2
16 Grommet holder 1
17 Grommet 1
18 Bolt M8
× 16 mm 4
19 Cap 1
20 Cap 1
21 Battery cable 1
22 Washer 1
23 Lead 1
24 Plastic tie 2
25 Plastic tie 1
26 Coupler 1
27 Lead 1
28 Cap 1
29 Lead 1
30 Plastic tie 1
31 Hose 1
32 Holder 1
33 Coupler 1
34 Coupler 1
35 Plastic tie 2
36 Bolt M6
× 16 mm 1
37 Coupler 1
38 Coupler 1
Part name
Q
’ty
Remarks
