Yamaha F400A 2022 - Direct Injection Pump and Fuel Injector

Direct injection pump and fuel injector
6-18
Direct injection pump and fuel injector
New
New
New
New
New
New
New
New
New
New
New
New
New
AA
AA
AA
EEE
EE
EE
EE
AA
10
9
9
8
8
22
23
24
21
20
1
1
2
2
6
11
12
13
12
16
19
14
17
15
16
18
19
13
16
12
16
12
11
7
6
6
7
3
4
5
7,14,15
3,5
10
2223 21 20
24
48 N
·
m (4.8 kgf
·
m, 35 lb
·ft
)
28 N
·
m (2.8 kgf
·
m, 21 lb
·ft
)
14 N
·
m (1.4 kgf
·
m, 10 lb
·ft
)
28 N
·
m (2.8 kgf
·
m, 21 lb
·ft
)
Part name
Q
’ty
Remarks
1 Plastic tie 2
2Cover 2
3 Fuel pipe (PORT) 1
4Bolt M6
× 14 mm 1
5 Fuel pipe (STBD) 1
6Bolt M6
× 35 mm 4
7 Direct injection pump 2
8Lifter 2
9O-ring 2
10 Plastic tie 2
11 Cover 2
12 Nut M6 4
13 Bolt M6
× 50 mm 4
14 Fuel rail (PORT) 1
With fuel
pressure
sensor
15 Fuel rail (STBD) 1
With fuel
pressure
sensor
16 Stud bolt M8 × 65 mm 4
17
Sub-wire harness
(PORT)
1
18
Sub-wire harness
(STBD)
1
19 Fuel injector 8
20 Stopper 8
21 O-ring 8
22 Backup ring 8
23 Seal 8
24 Spring 8
Part name
Q
’ty
Remarks
