7-22
Electrical management box
Electrical management box
*The locations of the spare fuses are not speci-
fied.
6
6
2
1
3
4
4
5
1
2
10*
9
7
8
6
AA
A
B
A
B
16 15* 14*
13*
12*
11*
11
11
10
15
13
12
14
12
15
13
14
14
13
12
3.2 N
·
m (0.32 kgf
·
m, 2.4 lb
·ft
)
7.6 N
·
m (0.76 kgf
·
m, 5.6 lb
·ft
)
Part name
Q
’ty
Remarks
1Nut M6 7
2Cap 7
3Lead 1
4Coupler 2
5
Extension wire har-
ness
1
6Bolt M6
× 16 mm 4
7
Electrical manage-
ment box
1
8Cover 1
9Screw M5
× 10 mm 10
10 Fuse 2 100 A
11 Fuse 6 70 A
12 Fuse 4 10 A
13 Fuse 4 30 A
14 Fuse 4 20 A
15 Fuse 4 15 A
16 Fuse puller 1
