Yamaha F400A 2022 - Exhaust Guide

Exhaust guide
9-25
Exhaust guide
17
17
18
18
19
5
4
4
6
15
15
16
12
7
21
20
1
2
8
9
10
14
14
11
13
12
3
20
18
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
WR-No.2WR-No.2
New
New
New
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1.3 N
·
m (0.13 kgf
·
m, 0.95 lb
·ft
)
1
2
1
2
Part name
Q
’ty
Remarks
1Bolt M6
× 12 mm 1
2Plate 1
3 Oil seal 1
4Clamp 2
5Hose 1
6Bolt M6
× 20 mm 2
7 Silencer 1
8Bolt M6
× 16 mm 1
9Nipple 1
10 Gasket 1
11 Holder 2
12 Bolt M6
× 12 mm 3
13 Bracket 1
14 Cap seal 4
15 Grommet 4
16 Bracket 1
17 Bolt M10
× 70 mm 16
18 Bolt M10
× 80 mm 4
19 Exhaust guide 1
20 Dowel 2
21 Gasket 1
Part name
Q
’ty
Remarks
