Yamaha F400A 2022 - Upper Case Assembly and Mount

9-20
Upper case assembly and mount
Upper case assembly and mount
AA
AA
AA
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
54 N
·
m (5.4 kgf
·
m, 40 lb
·ft
)
54 N
·
m (5.4 kgf
·
m, 40 lb
·ft
)
54 N
·
m (5.4 kgf
·
m, 40 lb
·ft
)
54 N
·
m (5.4 kgf
·
m, 40 lb
·ft
)
72 N
·
m (7.2 kgf
·
m, 53 lb
·ft
)
200 N
·
m (20 kgf
·
m, 148 lb
·ft
)
200 N
·
m (20 kgf
·
m, 148 lb
·ft
)
1
37
8
38
14
22
New
11
New
10
9
17
24
25
26
27
28
29
31
30
18
19
33
36
36
34
32
32
33
35
6
6
12
13
20
21
15
16
17
18
19
23
24
24
25
26
27
28
29
31
6
7
7
New
New
New
New
1
4
3
2
1
5
Part name
Q
’ty
Remarks
1 Plastic tie 4
2 Plastic tie 2
3 Corrugated tube 1
4 Protective tube 1
5 Plastic tie 1
6Bolt M6
× 12 mm 4
7Holder 2
8 Cap seal 1
9Lead 1
10 Lead 1
11 Plastic tie 1
12 Protector cover 1
13 Holder 2
14 Cap seal 1
15 Lead 1
16 Protector 1
17 Cap 2
18 Bolt M16
× 202 mm 2
19 Washer 2
20 Nut M14 2
21 Washer 2
22 Upper case assembly 1
23 Damper 1
24 Bolt M10
× 45 mm 4
25 Bracket 2
26 Washer 2
27 Lower mount 2
28 Washer 2
29 Washer 2
30 Ground lead 1
31 Bolt M14
× 227 mm 2
32 Bolt M10
× 40 mm 12
33 Bracket 2
34 Upper mount (PORT) 1
Red paint
marks
35 Upper mount (STBD) 1
Green paint
marks
36 Damper 2
37 Grommet 1
38 Grommet 1
Part name
Q
’ty
Remarks
