Yamaha F400A 2022 - Upper Case, Muffler, and Oil Pan

9-28
Upper case, muffler, and oil pan
Upper case, muffler, and oil pan
1
2
3
4
9
10
567
3
8
11
12
13
12
14
1
15
16
17
18
19
31
28
20
21
22
23
24
24
24
25
26
27
27
24
1
1
29
30
32
33
34
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
60 N
·
m (6.1 kgf
·
m, 44 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1
2
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1
2
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
42 N
·
m (4.2 kgf
·
m, 31 lb
·ft
)
1
2
1
2
1
2
New
New
New
New
New
New
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
572572
LTLT
WR-No.2WR-No.2
AA
AA
EE
Part name
Q
’ty
Remarks
1 Bolt M10
× 70 mm 12
2 Upper case 1
3Dowel 2
4 Rubber seal 1
5 Pipe 151 mm (5.9 in) 1
For X-tran-
som model
6 Pipe 278 mm (10.9 in) 1
For U-tran-
som model
7 Pipe 405 mm (15.9 in) 1
For E-tran-
som model
8 Rubber seal 1
9Bolt M6
× 30 mm 12
10 Bolt M10
× 70 mm 4
11 Muffler 1
12 Dowel 2
13 Gasket 1
14 Bushing 1
15 Grommet 1
16 Bolt M6
× 40 mm 2
17 Bolt M6 × 25 mm 1
18 Cover 1
19 Gasket 1
20 Spring 1
21 PCV 1
22 Grommet 1
23 Bolt M10
× 35 mm 1
24 Bolt M10
× 70 mm 18
25 Bolt M10
× 120 mm 3
26 Oil pan (upper) 1
27 Dowel 2
28 Gasket 1
29 Oil pan (lower) 1
30 Drain bolt M38 1
31 O-ring 1
32 Circlip 1
33 Strainer 1
34 Damper 1
Part name
Q
’ty
Remarks
