Starter motor and extension wire harness
7-29
Installing the starter motor
1. Install:
• Holder brackets
• Battery cable terminal
• Terminal cover
(when an isolator lead is not installed)
• Starter motor
•Holders
•Cap
• Starter motor cable
• Starter motor coupler
Installing the extension wire harness
1. Install:
•Holders
• Extension wire harness
•Caps
• Extension wire harness bolts
• Ground lead
(extension wire harness)
•Plastic tie
TIP:
Route the extension wire harness. See “Elec-
trical component and wire harness routing”
(5-1).
T
R
.
.
Starter motor cable nut
11 N·m (1.1 kgf·m, 8.1 lb·ft)
Starter motor cable bolt
11 N·m (1.1 kgf·m, 8.1 lb·ft)
T
R
.
.
Extension wire harness bolt
11 N·m (1.1 kgf·m, 8.1 lb·ft)
