7-30
Wire harness
Wire harness
7
8
9
9
4
4
6
2
1
3
5
4
10
11
4
11
12
8
13
Part name
Q
’ty
Remarks
1Bolt M6
× 16 mm 2
2 Bracket 1
3Holder 1
4Bolt M6
× 16 mm 6
5Holder 2
6Holder 1
7Holder 1
8O-ring 2
9Holder 3
10 Holder 1
11 Holder 3
12 Holder 1
13 Wire harness 1
