Yamaha F400A 2022 - Propeller Shaft Housing (Regular Rotation Model)

Propeller shaft housing (regular rotation model)
8-18
Propeller shaft housing (regular rotation model)
*1. Rotate the drive shaft by 10 turns or more.
DD
DD
GG
GG
GG
15
16
12
13
15 17 16
16 14
13
12 6
14
16
17
6
7
11
19
18
New
5
10
9
8
3
2
1
22
21
20
4
New
New
New
New
New
155 N
·
m (15.5 kgf
·
m, 114 lb
·ft
)
*1
250 N
·
m (25 kgf
·
m, 184 lb
·ft
)
1
2
3
Part name
Q
’ty
Remarks
1 Ring nut M142 1
2 Claw washer 1
3
Propeller shaft hous-
ing
1
4Key 1
5O-ring 1
6 Propeller shaft 1
7
Reverse gear shim
(T2)
—
8 Tapered roller bearing 1
9
Propeller shaft shim
(T4)
—
10 Washer 1
11 Reverse gear 1
12 Spring 1
13 Cross pin 1
14 Dog clutch 1
15 Slider 1
16 Ball 2
6.33 mm
(0.25 in)
(reference
data)
17 Shift plunger 1
18 Ball bearing 1
19 Thrust washer 1
20 Oil seal 2
21 Circlip 1
22 Needle bearing 1
Part name
Q
’ty
Remarks
