Yamaha F400A 2022 - Propeller and Water Inlet Cover

8-1
Propeller and water inlet cover
Propeller and water inlet cover
A. For regular rotation model
B. For counter rotation model
DD
1
2
3
4
New
22
5
7
8
12
11
15
16
17
21
20
6
New
New
New
19
18
14
13
10
9
New
A
B
80 N
·
m (8.0 kgf
·
m, 59 lb
·ft
)
2.5 N
·
m (0.25 kgf
·
m, 1.8 lb
·ft
) 2.5 N
·
m (0.25 kgf
·
m, 1.8 lb
·ft
)
Part name
Q
’ty
Remarks
1 Cotter pin 1
2 Propeller nut M18 1
3Washer 1
4 Spacer 1
5 Propeller 1
6 Propeller 1
7 Spacer 1
8Bolt M6
× 57 mm 1
9
Water inlet cover
(PORT)
1
10 Self-locking nut M6 1
11
Water inlet cover
(STBD)
1
12 Bolt M6
× 57 mm 1
13
Water inlet cover
(PORT)
1
14 Self-locking nut M6 1
15
Water inlet cover
(STBD)
1
16
Oil level plug
M8
× 8 mm
1
17 O-ring 1
18
Drain screw
M18
× 12 mm
1
19 O-ring 1
20
Oil filler plug
M8
× 8 mm
1
21 O-ring 1
22 Damper 1
Part name
Q
’ty
Remarks
