Yamaha F400A 2022 - Exhaust Joint (Inside)

Exhaust joint (inside)
7-11
Exhaust joint (inside)
3
3
10
11
11
13
12
10
13
12
1
2
1
2
10
11
13
12
10
11
13
12
8
8
5
7
8
8
9
9
9
New
New
New
New
New
New
EE
13031303
EE
EE
4
6
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
21 N
·
m (2.1 kgf
·
m, 15 lb
·ft
)
14 N
·
m (1.4 kgf
·
m, 10 lb
·ft
)
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
21 N
·
m (2.1 kgf
·
m, 15 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M8
× 120 mm 10
2Bolt M8
× 50 mm 10
3Nut M8 4
4 Exhaust joint 1 PORT
5Gasket 1
6 Exhaust joint 1 STBD
7Gasket 1
8Dowel 4
9Stud bolt M8
× 65 mm 4
10 Plug M16
× 11 mm 4
11 O-ring 4
12 Screw M5
× 25 mm 4
13 Anode 4
