Yamaha F400A 2022 - Extension (Except for X-Transom Model)

8-9
Extension (except for X-transom model)
Extension (except for X-transom model)
A. For E-transom model
*. Use white sealant for white-colored units.
13221322
13221322
572572
LTLT
572572
LTLT
13221322
572572
LTLT
572572
LTLT
13221322
7
9
New
5
New
6
3
2
1
3
4
New
8
New
18
New
14
New
15
12
11
10
12
13
New
17
New
14
New
16
A
New
15
12
11
12
13
New
17
New
16
23 N
·
m (2.3 kgf
·
m, 17 lb
·ft
)
23 N
·
m (2.3 kgf
·
m, 17 lb
·ft
)
47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
) 47 N
·
m (4.7 kgf
·
m, 35 lb
·ft
)
**
**
**
Part name
Q
’ty
Remarks
1 Bolt M10
× 45 mm 1
2Extension 1
3Dowel 2
4 Rubber seal 1
5O-ring 1
6Nipple 1
7O-ring 1
8Nipple 1
9
Stud bolt
M10
× 185 mm
8
Point the flat
end of the
stud bolt up.
10 Bolt M10
× 174 mm 1
11 Extension 2
12 Dowel 4
13 Rubber seal 2
14 O-ring 2
15 Nipple 2
16 O-ring 2
17 Nipple 2
18
Stud bolt
M10
× 312 mm
8
Point the flat
end of the
stud bolt up.
Part name
Q
’ty
Remarks
