Yamaha F400A 2022 - Ignition Coil and Spark Plug

7-40
Ignition coil and spark plug
Ignition coil and spark plug
4
5
3
2
1
4
2
3
5
1
10 N
·
m (1.0 kgf
·
m, 7.4 lb
·ft
)
11 N
·
m (1.1 kgf
·
m, 8.1 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M6
× 30 mm 8
2 Ignition coil 8
3 Spark plug 8
4Bolt M6
× 20 mm 16
5 Bracket 8
