2-29
Electrical system
Electrical system
Charging system (F400A/FL400A/XF400)
This model is equipped with a 3-phase AC magneto type generator. In addition, because the cooling
efficiency of the rectifier/regulator “1” is increased and the temperature increase is controlled by the
fan “3” on top of the stator assembly “2”, the 400-horsepower models produce of up to 88 net amps
per engine at 1500 r/min.
A circuit for detecting the battery voltage has been added to the rectifier/regulator. Because the
charging of the house battery circuit is cut off when an instantaneous voltage drop occurs when the
SBW (Steer by Wire) system or PTT unit is operated, stable power can be supplied to the electrical
components of the engine. As a result, this model can use the same batteries as those of previous
models. (This function operates when the boat is equipped with an engine battery and a house battery,
and the isolator lead is connected.)
