Yamaha F400A 2022 - Water Pump and Shift Rod

8-11
Water pump and shift rod
Water pump and shift rod
A. For regular rotation model
B. For counter rotation model
572572
LTLT
572572
LTLT
1530D1530D
1322D1322D
1322D1322D
17
New30
18
8
5
1
2
28
27
26
7
New
29
New
25
24
New
19
23
22
6
New
13
New
4
New
21
AB
12
20
12
3
3
11
10
9
16
15
14
New
32
New
31
New
16 N
·
m (1.6 kgf
·
m, 12 lb
·ft
)
4.5 N
·
m (0.45 kgf
·
m, 3.3 lb
·ft
)
4.5 N
·
m (0.45 kgf
·
m, 3.3 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M8
× 70 mm 4
2 Water pump housing 1
3Dowel 2
4O-ring 1
5Impeller 1
6Impeller key 1
7 Outer plate cartridge 1
8O-ring 1
9Bolt M5
× 10 mm 2
10 Impeller 1
11 Water pump housing 1
12 Dowel 2
13 O-ring 1
14 Bolt M5
× 16 mm 2
15 Spacer 1
16 Spacer 1
17 Bolt M8
× 35 mm 6
18 Plate 1
19 O-ring 1
20 Plate 1
21 Gasket 1
22 Shift rod 1
23 E-clip 1
24 Insert cartridge 1
25 O-ring 1
26 Guide 1
27 Seal 1
28 Cover 1
29 Oil seal 1
30 Oil seal 1
31 Check valve 1
32 Check valve 1
Part name
Q
’ty
Remarks
