Yamaha F400A 2022 - PTT Unit

PTT unit
9-45
PTT unit
1
2
3
4
New
New
New
5
6
7
8
9
10
11
12
13
13
13
13
12
14
15
15
572572
LTLT
AA
AA
AA
AA
572572
LTLT
271271
LTLT
271271
LTLT
271271
LTLT
DD
55 N
·
m (5.5 kgf
·
m, 41 lb
·ft
)
55 N
·
m (5.5 kgf
·
m, 41 lb
·ft
)
55 N
·
m (5.5 kgf
·
m, 41 lb
·ft
)
55 N
·
m (5.5 kgf
·
m, 41 lb
·ft
)
3.6 N
·
m (0.36 kgf
·
m, 2.7 lb
·ft
)
3.3 N
·
m (0.33 kgf
·
m, 2.4 lb
·ft
)
Part name
Q
’ty
Remarks
1Pin 1
2Bolt M6
× 14 mm 1
3Plate 1
4Lead 1
5Bolt M5
× 16 mm 2
6Sensor 1PTT
7O-ring 1
8Bolt M5
× 16 mm 2
9 Adapter 1
10 O-ring 1
11 Shaft 1
12 Bolt M10
× 75 mm 2
13 Bolt M10
× 35 mm 6
14 PTT unit 1
15 Bushing 2
